5.3.9.3 Parallel Port Configuration
Use the Parallel Port Configuration menu (BIOS Menu 15) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=5
Change Settings
[Auto]
Device Mode [Printer Mode]
Enable or Disable
Parallel Port (LPT/LPTE)
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: Parallel Port Configuration Menu
Parallel Port [Enabled]
Use the Parallel Port option to enable or disable the parallel port.
Disabled Disable the parallel port
Enabled D EFAULT Enable the parallel port
Change Settings [Auto]
Use the Change Settings option to change the parallel port IO port address and interrupt
address.
Auto D EFAULT The parallel port IO port address and interrupt
address are automatically detected.
IO=378h;
IRQ=5
Parallel Port I/O port address is 378h and the
interrupt address is IRQ5
