ICE-CV-D25502/N26002 COM Express Module
Page 44
5.3.8 Secondary Super IO Configuration
Use the Secondary Super IO Configuration menu (BIOS Menu 10) to set or change the
configurations for the serial ports.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Secondary Super IO Configuration
Super IO Chip
Fintek F81216
> COM 3 Configuration
> COM 4 Configuration
> COM 5 Configuration
> COM 6 Configuration
Set Parameters of Serial
Port 2 (COMC)
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: Secondary Super IO Configuration
5.3.8.1 COM n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 11) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
COM n Configuration
Serial Port [Enabled]
Device Settings IO=2C0h; IRQ=10
Change Settings
[Auto]
Enable or Disable Serial
Port (COM)
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: COM n Configuration Menu
