ICE-CV-D25502/N26002 COM Express Module
Page 49
5.3.9.1 Floppy Disk Controller Configuration
Use the Floppy Disk Controller Configuration menu (BIOS Menu 14) to configure the
floppy disk controller.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Floppy Disk Controller Configuration
Floppy Disk Controller [Enabled]
Device Settings IO=3F0h; IRQ=6; DMA=2
Enable or Disable Floppy
Disk Controller
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: Floppy Disk Controler Configuration Menu
Floppy Disk Controller [Enabled]
Use the Floppy Disk Controller option to enable or disable the floppy disk controller.
Disabled Floppy disk controller disabled
Enabled D EFAULT Floppy disk controller enabled
Change Settings [Auto]
Use the Change Settings option to select an optimal setting for the device.
Auto D EFAULT The IO port address, interrupt address and DMA are
automatically detected.
IO=3F0h;
IRQ=6;
DMA=2
The I/O port address is 3F0h; the interrupt address is
IRQ6; the DMA is 2.
