ICE-CV-D25502/N26002 COM Express Module
Page 6
1.7 Technical Specifications
The ICE-CV-D25502/N26002 technical specifications are listed below.
Specifications/Model ICE-CV-D25502/N26002
Form Factor
PICMG COM Express R2.0 Type 2 for compact size (95 mm x 95 mm)
10 layers
CPU
1.86 GHz Intel® Atom™ D2550 dual-core CPU (2 x 512KB L2 cache)
1.6 GHz Intel® Atom™ N2600 dual-core CPU (2 x 512KB L2 cache)
PCH Intel® NM10
Memory
D2550: One 1066 MHz DDR3/DDR3L (1.35V) SO-DIMM support (up to
4 GB)
N2600: One 800 MHz DDR3/DDR3L (1.35V) SO-DIMM support (up to
2 GB)
Graphics Engine
D2550: Intel® GMA 3650 with 640 MHz graphics core speed
N2600: Intel® GMA 3600 with 400 MHz graphics core speed
Supports DirectX 9 and Blu-ray 2.0
MPEG2, H.264, VC-1 and 1080p decoding
Display
(Signal to Baseboard)
One VGA is integrated in the CPU
One LVDS is integrated in the CPU:
D2550: 24-bit single-channel LVDS
N2600: 18-bit single-channel LVDS
Ethernet Realtek RTL8111E PCIe GbE controller
BIOS UEFI BIOS
Embedded Controller iWDD
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
(Signal to Baseboard)
Three PCIe x1
Supports PCI
