5.3.7 iWDD H/W Monitor
The iWDD H/W Monitor menu (BIOS Menu 9) allows configuring the CPU fan speed
value and displays the CPU fan speed and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU FAN1 Speed : N/A
CPU Fan Speed Value 100
VINO(+1.5V_DDR3)
: +1.513 V
VIN1(+VCC_CPU) : +1.196 V
VIN2(+V1.05S) : +1.058 V
VIN3(+V1.5S) : +1.507 V
VIN4(+V1.8S) : +1.780 V
VIN5(+V3.3S) : +2.997 V
VIN6(+V5S) : +5.160 V
VIN7(+V12S) : +12.052 V
Set CPU Fan Speed Value
0~127
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 9: iWDD H/W Monitor
CPU Fan Speed Value
Use the + or – key to change the CPU fan speed value. Enter a decimal number between
0 and 127.
