ICE-CV-D25502/N26002 COM Express Module

Page 23

3.2.3 SO-DIMM Connector

CN Label:

DIMM1

CN Type:

204-pin DDR3 SO-DIMM connector

CN Location:

See Figure 3-4

The SO-DIMM connector is for installing memory on the system.

Figure 3-4: SO-DIMM Connector Location

3.2.4 SPI Connector

CN Label:

SPI1

CN Type:

6-pin connector

CN Location:

See Figure 3-5

CN Pinouts:

See Table 3-4

The SPI connector is for flashing new BIOS onto the SPI BIOS chip.
