IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11
IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
Select RS232/422/485 [RS232]
Use the Select RS232/422/485 option to select the serial port mode.
RS232 D EFAULT Enables serial port RS-232 support.
RS422/RS485 Enables serial port RS-422/485 support.
5.3.9 Super IO Configuration
Use the Super IO Configuration menu (BIOS Menu 12) to set or change the
configurations for the serial ports.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Super IO Configuration
Super IO Chip
Winbond W83627EHG
> Floppy Disk Controller Configuration
> COM 1 Configuration
> COM 2 Configuration
> Parallel Port Configuration
Set Parameters of Floppy
Disk Controller (FDC)
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 12: Super IO Configuration
