ICE-CV-D25502/N26002 COM Express Module
Page 50
Device Mode [Read Write]
Use the Device Mode option to select the device mode.
Read Write D EFAULT Enables for normal operation.
Write Protect Enables for read only operation.
5.3.9.2 COM n Configuration
Use the COM n Configuration menu (BIOS Menu 14) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings
[Auto]
Enable or Disable Serial
Port (COM)
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 14: COM n Configuration Menu
5.3.9.2.1 COM 1 Configuration
Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Disabled Disable the serial port
Enabled D EFAULT Enable the serial port
Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
