PICOe-PV-D4251/N4551/D5251 User Manual
Page 7
Specification PICOe-PV-D4251/N4551/D5251
Display One VGA port (supports up to 2048x1536 resolution for D525/D425 or
1400x1050 for N455)
One 18-bit single-channel LVDS via internal connector (supports up
1024x768 (XGA) and 1366x768 (WXGA) resolution)
Ethernet Two RJ-45 GbE ports
Audio Supports 7.1 channel HD audio via optional IEI AC-KIT883HD kit
Keyboard/Mouse One PS/2 KB/MS port
One KB/MS via internal header
Parallel Port One Parallel (LPT) port connector
Serial Ports Three RS-232 serial ports via internal box header
One RS-232/422/485 serial ports via internal box header
USB 2.0/1.1 ports One USB port
Six USB via internal pin headers
Storage
CompactFlash® One CompactFlash® Type II
Serial ATA Three independent Serial ATA (SATA) channels with 3.0 Gb/s
data transfer rates
Environmental and Power Specifications
Power Supply 5 V / 12 V, AT/ATX power support
Power
Consumption
[email protected], [email protected] (Intel® Atom™ Dual Core D525 1.80GHz with
1GB DDR3 800MHz Memory on board)
[email protected], [email protected] (Intel® Atom™ Dual Core D425 1.80GHz with
1GB DDR3 800MHz Memory on board)
[email protected], [email protected] (Intel® Atom™ Single Core N455 1.66GHz with
1GB DDR3 800MHz Memory on board)
