R S ERIES — P ULSE O XIMETRY (S P O
2
) O PTION I NSERT
16 www.zoll.com 9650-0901-01 Rev. D
Specifications
The following specifications apply to the R Series pulse oximeter only. For information about
the R Series defibrillator and batteries, refer to your defibrillator’s R Series Operator’s Guide.
CHECK SPO2 SITE Insufficient perfusion at the sensor
site Reposition or relocate the
sensor, or increase perfusion.
CHECK SPO2 SENSOR An inappropriate sensor site, poor
application of the sensor, no
patient cable plugged in, or motion
is causing invalid SpO
2
readings.
Reposition or relocate the
sensor, or increase perfusion.
Ensure that the cable is
plugged into the unit.
Cease motion.
Dashes appear in place
of the SpO
2
saturation
percentage.
Excessive ambient light,
inadequate perfusion, high signal
artifact, or a defective or
disconnected sensor or patient
cable Reposition or relocate the
sensor, reduce the ambient
light, shield the sensor from the
light, or increase perfusion.
Check the cable and sensor.
Message:
SPO2 COMM ERROR
The pulse oximeter subsystem is
not communicating with the
defibrillator. Turn unit off and then back on
to see if message clears. If
message persists, contact
ZOLL Technical Service.
Message or Symptom Possible Causes Recommended Action
General
Saturation range (%SpO
2
) 1% to 100%
Saturation resolution 1%
Saturation accuracy *
Note: R Series defibrillators are
designed to work with the
Masimo LNCS series of
sensors and are dependent on
their specifications. Refer to
Masimo LNCS sensor labeling
for accuracy information.
During no-motion conditions
Adults/pediatrics: 70% to 100%, ±2%
0% to 69%, unspecified
Neonates: 70% to 100%, ±3%
0% to 69%, unspecified
During motion conditions
All patients: 70% to 100%, ±3%
0% to 69%, unspecified
Saturation alarm limits On/Off displayed on monitor; operator-selectable.
Low limit: 70% to 98%
High limit: 72% to 100%
SpO
2
Wavelength Nominal Red LED Wavelength: 660 nanometers
Nominal Infrared LED Wavelength: 905 nanometers
Energies (Radiant Power) of light for
LNCS Sensors at 50 mA pulsed Minimum: 0.13 mW
Maximum: 0.79 mW
Pulse rate range 25 to 240 beats per minute
Pulse rate resolution 1 beat per minute
