9650-0218-01 Non-Interpretive 12-lead - 1 Rev. B
NON–INTERPRETIVE 12-LEAD ECG
MONITORING
ECG leads are a defibrillation protected Type CF patient connection.
General Information
Product Description
ZOLL M Series with non-interpretive 12-lead option provides simultaneous 12-lead ECG acquisition, storage, display, and
transmission.
Intended Use
The ZOLL M Series with non-interpretive 12-lead ECG monitoring is intended for the recording and transmission of 12-lead
ECG signals acquired from adult and pediatric patients in the supine, resting position.
Indications
The 12-lead ECG is useful in the diagnosis and treatment of patients with acute myocardial infarction (AMI). 12-lead ECG is
also useful in the interpretation and documentation of other transient cardiac arrhythmias that may occur. When used in the
prehospital setting, the 12-lead ECG can be of assistance in diagnosis and treatment decisions once the patient has arrived
in the hospital emergency department.
How to Use This Manual
This manual provides instructions for using the ZOLL M Series with non-interpretive 12-lead option. It does not contain
information on how to read or interpret electrocardiograms (ECGs ). It covers the following:
• Warnings
• Electrode Placement
• 12-Lead Acquisition
• 12-Lead ECG Data Transmission
• 12-Lead Reports
• Daily Operational Verification
• Troubleshooting
