Drawer Assembly
Drawer urder-side view with cover removed.
NHPL-1836-ECO
NHPL-1836
NHPL-1825-UN
NHPL-1810/HH
INHPL-1836
HEATER PROOFER
POWER SUPPLY
120VAC 60Hz
13.5 AMP
For technical
assistance
please e-mail:
[email protected]
For Service and Parts call:
1-800-444-3595
(5)
(2A)
(6)
(9)
(12)
(10)
(11)
(3)
(4)
(2)
(1)
(1) (2) (3) (13) (14)
800-444-3595 | fax: 516-921-0538 | www.winholt.com 4
Part Location
Heater Drawer Parts List
Cabinet Parts List
1
2
2A
3
4
5
6
9
10
11
12
13
14
Replacement Drawer - All Models
Replacement Drawer - Universal Angle
Main Power Switch
L.E.D. Thermometer
Thermometer Transformer
Heat/Proof Switch
Thermostat (Heat)
Thermostat (Proof)
Blower and Motor Assembly
Power Inlet Terminal Board
1000W Heater Element
600W Heater Element
600W Water Pan Heater Element
Heat Control Knob
Proofer Control Knob
Cord Set
Replacement Door Lexan (Universial Runner)
Replacement Door Lexan (All Others)
Replacement Door Lexan (Undercounter)
Plastic Door Handle
595753
642396
232805
123887
232784
170851
170894
632868
170907
170915
170923
123916
632850
657459
247505
657432
233656
NHPL-PD-CH
NHP-PD-UN
H-106-2
H-105
H-106
H-220
H-225
H-125
H-226
H-227
H-228
H-108
H-103-1
NHPL-DR/UN
NHPL-DR
NHPL-DR/HH
H-323-2
Part Description Order# Model#
