Dunnage Racks Economy
Prolongs product life by circulating air underneath.
12" height above floor meets all sanitary health codes.
All welded 1½" x 1½" heavy duty, rustproof aluminum
tube construction.
Model
Number
Ordering
Number
Length
Capacity
Approx.
Ship Wt
(in) (mm) (lb) (kg) (lb) (kg)
20" (508mm) Width x 12" (305mm) Height
DASQ-3-1220 133866 36 914 2100 953 8 4
DASQ-4-1220 133874 48 1,219 1800 816 11 5
DASQ-5-1220 133882 60 1,524 1500 680 12 5
24" (610mm) Width x 12" (305mm) Height
DASQ-3-1224
E XPRESS
S HIP
133891 36 914 2100 953 10 5
DASQ-4-1224
E XPRESS
S HIP
133903 48 1,219 1800 816 12 5
DASQ-5-1224 133911 60 1,524 1500 680 14 6
20" (508mm) Width x 8" (203mm) Height
DASQ-3-820 156161 36 914 2100 953 10 5
DASQ-4-820 154018 48 1,219 1800 816 12 5
DASQ-5-820 153550 60 1,524 1500 680 14 6
24" (610mm) Width x 8" (203mm) Height
DASQ-3-824 138237 36 914 2100 953 10 5
DASQ-4-824 138245 48 1,219 1800 816 12 5
DASQ-5-824 153568 60 1,524 1500 680 14 6
Freight Class: 70
DASQ Series
Economy
1½” x 1½”
Tubular Frame
G OOD
L IGHT D UTY U SE
L IFE W ARRANTY
A GAINST R UST
Equipment Guide
Model
Number
Ordering
Number
Length Capacity
Approx.
Ship Wt
(in) (mm) (lb) (kg) (lb) (kg)
20" (508mm) Width x 12" (305mm) Height
ALSQ-3-1220 102971 36 914 3000 1,361 8 4
ALSQ-4-1220 103085 48 1,219 2500 1,134 10 5
ALSQ-5-1220 103202 60 1,524 2000 907 12 5
24" (610mm) Width x 12" (305mm) Height
ALSQ-3-1224 102980 36 914 3000 1,361 10 5
ALSQ-4-1224 103093 48 1,219 2500 1,134 12 5
ALSQ-5-1224 103211 60 1,524 2000 907 14 6
20" (508mm) Width x 8" (203mm) Height
ALSQ-3-820 103034 36 914 3,000 1,361 10 5
ALSQ-4-820 103181 48 1,219 2,500 1,134 12 5
ALSQ-5-820 103245 60 1,524 2,000 907 14 6
24" (610mm) Width x 8" (203mm) Height
ALSQ-3-824 103042 36 914 3000 1,361 10 5
ALSQ-4-824 103190 48 1,219 2500 1,134 12 5
ALSQ-5-824 103253 60 1,524 2000 907 14 6
Dunnage Racks Heavy Duty
Prolongs product life by circulating air underneath.
12" (305mm) height off the ground meets all sanitary health
codes.
Straight Tube Dunnage Racks—supports high capacity loads
on all welded 1¾" x 1½" tube aluminum construction.
B ETTER
H EAVY D UTY U SE
L IFE W ARRANTY
A GAINST R UST
Equipment Guide
Freight Class: 70
ALSQ Series
1¾” x 1½”
Tubular Frame
W IN -H OLT D UNNAGE R ACK
C
APACITY
G
UIDE
Series
36”
Length
48”
Length
60”
Length
DASQ 2100 lb 1800 lb 1500 lb
ALSQ 3000 lb 2500 lb 2000 lb
ALCH 3000 lb 2500 lb 2000 lb
DRAL 3000 lb 2500 lb 2000 lb
