2.4.3 INSPECTION OF MOTOR
• Visual inspection.
• Ensure that Motor has been properly placed inside the End Housing and the screw had
been properly tightened
2.5 WIRE ROPE ASSEMBLY
2.5.1 REMOVAL OF WIRE ROPE
Note:
Prior to disassembly
:
1. Spool out all Wire Rope.
2. Use of gloves is recommended while handling frayed or damaged Wire Rope.
3. Unplug unit / remove Battery before disassembly.
Tasks:
Disassemble the Wire Rope.
1. Push the Wire in the direction of the
arrow mark as shown in the figure.
