986767A2.doc

Page 15 of 45

5. Keep the assembly on the work bench

facing the cover in the direction shown in
the figure.

6. Install 6 bolts (#8 X 1.25) from the main

body of the Housing.

7. Install 6 bolts (#6 x .75) in Handle .

Note:

When replacing the Housings with a Housing Service kit, be sure to affix ALL

appropriate labels from the service kit onto the new housings, using the housings
being replaced as a guide for placement of your new labels. Your service kit will
include extra labels for other languages and markets that can be discarded after you
select the ones needed for your product.
