Specifications
Model # NE-CART-1 NE-CART -2 NE-CART -3 NE-CART-4
Total Capacity 750 lbs 500 lbs 750 lbs 400
2nd Shelf Capacity N/A 250 lbs N/A 200
3 rd Shelf Capacity N/A N/A N/A 150
Platform Size (L x W) 28 x 48” 24¾” x 46” 24¾” x 46” 24¾” x 46”
2
nd
deck platform size (L x W) N/A 24¾” x 46” N/A 24¾” x 46”
2 nd deck platform size (L x W) N/A N/A N/A 24¾” x 46”
Platform Height 14” 14” 14” 14”
2 nd Deck Height N/A 33” N/A 33”
3
rd
Deck Height N/A N/A N/A 49¾”
Distance between the
platforms N/A 17¾” N/A 17¾” (1 & 2) 16¾” (2 & 3)
Steering wheel (2) Ø9 x 3⅛” (solid-foam tires) (2) Ø9 x 3⅛” (solid-foam tires) (2) Ø9 x 3⅛” (solid-foam tires) (2) Ø9 x 3⅛” (solid-foam
tires)
Drive wheel (2) Ø10¼ x 3⅛” (solid-foam
tires)
(2) Ø10¼ x 3⅛” (solid-foam
tires)
(2) Ø10¼ x 3⅛” (solid-foam
tires)
(2) Ø10¼ x 3⅛” (solid-
foam tires)
Overall Size (L x W x H) 59 x 28 x 44 11/16” 59 x 28 x 44 11/16” 59 x 28 x 44 11/16” 59 x 28 x 59⅜”
Handle Height 44 11/16” 44 11/16” 44 11/16” 44 11/16”
Railing Height N/A 40” 12” 59¾”
Loaded 2.5 mph 2.5 mph 2.5 mph 2.5 mph Travel Speed
(Fast)
Unloaded 2.8 mph 2.8 mph 2.8 mph 2.8 mph
Loaded 1.3 mph 1.3 mph 1.3 mph 1.3 mph Travel Speed
(Slow)
Unloaded 1.5 mph 1.5 mph 1.5 mph 1.5 mph
Turning Radius 23⅝” 23⅝” 23⅝” 23⅝”
Controller Curtis 1212 Curtis 1212 Curtis 1212 Curtis 1212
Drive Motor DC24V/500W DC24V/500W DC24V/500W DC24V/500W
Battery 2 x 12V/80-95Ah 2 x 12V/80-95Ah 2 x 12V/80-95Ah 2 x 12V/80-95Ah
Battery Charger DC 24V/6A DC 24V/6A DC 24V/6A DC 24V/6A
Frame
Height: 25¾” Frame Height: 11½” Frame height: 45⅜”
Hi/Low speed
Variable speed control throttle
24V Battery system
Battery Level Indicator
Automatic Brake
Steel Construction
Tread plate surface
Maximum incline is 7 degrees
On-board battery Charger (3-4 hour operation at full charge - 8 hours when used intermittently)
Horn & Belly-bump emergency safety stop.
