Vestil NE-CART User Manual
Page 32
E-CART (ELECTRIC CART)
32
Filename: Belly Switch trouble shoot
This shows sliding the red tabs over the black nub. This is basically the reverse of Fig6.
Fig.27
This is the top front where the two connectors are. Make sure they are on each side of the stand off
so the wires do not get pinched. Fig28
Fig.28
Stand off
between
connectors
Black nub
Red tab
