Vestil LDLT series User Manual
Page 8
8
EXPLODED PARTS DRAWING
1& 2-POST HYDRAULIC TABLE
6
1
2a
4
3a
5
PARTS LIST
1 & 2-POST HYDRAULIC TABLES
DESCRIPTION
Foot Pump (FHJ-18 style)
Foot Pump Mt. Bolts 1/4-20 x 2
Nut 1/4-20 Nylock
Washer 1/2-20 Flat Washer
Casters 3-1/2 x 1-1/4 Polyurethane
Caster with Total Locks, Polyurethane
Bolt, Caster Mt. 1/4-20 x 3-1/2, or equivalent
Bolt 3/8-16 unc x 5 Carriage Bolt, or equivalent
Nut, Nylock Caster Mt. 1/4-20
Nut 3/8-16
Pin, Upper Cylinder Mt. (roller pin) 3/16 x 1-1/2
5 x 2 Poly-on-Steel Rigid Caster
5 x 2 Poly-on-Steel Swivel with Lock
Seal Kit Foot Pump
Caster Kit (includes either 3a or 3b)
HD Caster Kit (see page 10)
ITEM NO.
1
2a
2b
2c
3a
3b
4a
4b
5a
5b
6
6a
6b
A
B
C
ENGINEER NO.
01-640-030
a/l
a/l
a/l
16-132-003
16-132-002
a/l
a/l
a/l
a/l
a/l
16-132-022
16-132-03
01-136-412
21-154-009
16-154-020
PART NO.
HT2-FTP
a/l
a/l
a/l
HT2-CSTR
HT2-CSTRTL
a/l
a/l
a/l
a/l
a/l
HT2-HDCSTR
HT2-HDLCSTR
HT2-KITA
HT2-KITB
HT2-KITC
QTY.
1
2
2
2
4
4
4
4
1
-
-
2
2
1
1
1
*See page 9 for Two-Post Table Exploded Drawing
a/l - Available at Local Hardware Store
