11
PARTS LIST
A/L Available at local hardware store
A/K Available only with purchase of kit
DC POWERED POST TABLES
DESCRIPTION
Motor
Pump
Bolt Motor/Pump Mt. 3/8-16 x 1
Hand Control
Hydraulic Hose Assembly Pressure
Hydraulic Hose Assembly Return
Battery
Motor, Solenoid Smart Start Switch
Battery Box, Strap
ITEM NO.
30
31
32
34
35
36
38
37
39
ENGINEER NO.
01-135-042
01-143-010
a/l
01-522-022
21-523-003
21-523-004
21-139-003
15-022-004
21-154-010
PART NO.
HTDC-MTR
HTDC-PMP
a/l
HTDC-HC
HTDC-HHAP
HTDC-HHAR
HTDC-BATT
HTDC-SOL
HTDC-BBS
QTY.
-
-
-
-
-
-
-
-
-
DESCRIPTION
Foot Pump, Two Speed
Bolt, Foot Pump Mt. 3/8-16 x 3
Nut, Foot Pump Mt. 3/8-16
Cylinder 1-1/8 x 18
Cylinder 1-3/4 x 18
Bolt, Cylinder 3/8-16 x 1-1/4
Nut, Cylinder 3/8-16
Casters, Rigid 4 x 2 Phenolic
Caster, Swivel 4 x 2 Phenolic with Brake
Bolt, Caster Mt. 3/8-16 x 5 Lg.
Nut, Caster Mt. 3/8-16
Hose Assembly - Pressure
Hose Assembly - Return
Bolt Caster, 3/8-16 x 1 (6,000 lb. unit only)
Nut Lock, Caster 3/8-16 x 1 (6,000 lb. unit only)
Washer 3/8 (not shown) (6,000 lb. unit only)
Seal Kit for Foot Pump
ITEM NO.
1
2
3
4a
4b
5
6
7a
8a
9
10
11
12
13
14
15
1a
ENGINEER NO.
01-640-004
a/l
a/l
21-021-006
21-021-005
a/l
a/l
16-132-016
16-132-148
a/l
a/l
21-523-001
21-523-002
a/l
a/l
a/l
01-136-441
PART NO.
HT4-2SFP
a/l
a/l
HT4-CYL
HT6-CYL
a/l
a/l
HT4-RGPHN
HT4-SWPHN
a/l
a/l
HT4-PSRHA
HT4-RTNHA
a/l
a/l
a/l
HT4-FP-SK
QTY.
1
2
2
1
1
2
2
2
2
4
4
1
1
16
16
16
1
4-POST & DC POWERED HYDRAULIC POST TABLES
