15
PARTS LIST FOOT OPERATED HYDRAULIC JACK - MODEL FHJ-C
1 FHJ-P103 Snap Ring 2
2 FHJ-P104 Spring Holder 1
3 FHJ-P102 Plunger 1
4 FHJ-P105 Pressure Spring 1
K 5 FHJ-P106 Rod Wiper 1
K 6 HYD-02-2706 O-Ring 1
7 FHJ-P113 Check Valve Plug 1
K 8 HYD-01-2514 O-Ring 1
9 PLT-P1036 Valve Spring 1
10 PLT-P1037 Cone Valve 1
11 PLT-P1038 Cone Valve Seat 1
K 12 HYD-01-0803 O-Ring 2
13 SB-9-32 Steel Ball 1
14 FHJ-P153 Roller 1
15 FHJ-P151 Snap Ring 4
16 FHJ-P152 Pedal Pin 2
17 FHJ-P168 Foot Pedal 1
18 SB-5-32 Steel Ball 1
19 FHJ-P111 Relief Seat 1
20 FHJ-P110 Relief Spring 1
21 FHJ-P109 Relief Plug 1
22 FHJ-P121 Lowering Pedal Spring 1
23 FHJ-P119 Lowering Pedal 1
24 FHJ-P147 Filler Breather Plug 1
25 FHJ-P150 Pedal Crimp Spring 1
26 FHJ-P148 Lock Washer 1
27 FHJ-P149 Screw 1
K 28 FHJ-P107 Back-Up Ring 1
K 29 FHJ-P166 Dust Seal 1
K 30 FHJ-P167 Rod Seal 1
K 31 CYL-M0010-020 Dyna Seal 1
32 FHJ-P135 Gland Nut 1
33 FHJ-P163 Socket Head Cap Screw 1
K 34 HYD-02-2811 O-Ring (Gland) 1
K 35 HYD-02-6038 O-Ring (Inner Tube) 2
36 FHJ-P156-3020-00 Piston Rod 1
37 FHJ-P141-2424 Inner Tube 1
38 FHJ-P101-2424 Base & Tube Weldment 1
39 FHJ-P129 Bolt 1
40 FHJ-P130 Lock Washer 1
41 FHJ-P1015 Valve Spring 1
42 FHJ-P123 Pressure Pin 1
K 43 HYD-01-2506 O-Ring 1
44 FHJ-P124 Bushing 1
K 45 HYD-01-2637 O-Ring 1
46 FHJ-P122 Lowering Spacer 1
47 FHJ-P120 Lowering Sleeve 1
48 FHJ-P128 Set Screw 1
49 FHJ-P118 Push Bolt 1
50 FHJ-P164 Lock Nut 1
51 FHJ-P139 Piston 1
52 FHJ-P165 Snap Ring 1
A FHJ-SK Seal Kit 1
K Available in seal kit only
ITEM # PART NUMBER DESCRIPTION QUANTITY
