PARTS IDENTIFICATION
GROUND TILTER • GLT-4000
DESCRIPTION
Clevis Pin 1 x 3-1/4
Cylinder 2 x 8
Hair Pin Clip
Clevis Pin 1 x 2-1/4
Right Side Guard
Screw 5-1/6-18 x 1/2 Self Tapping
Plastic Guard 12 x 51
Machiner Screw 5/16-18 x 1-1/4
Toe Guard with Bevel
Fender Washer 5/16
Sensor Bracket
Lock Nut 5/16-18
Cross Bar
Toe Guard Bolt
Machine Screw 8-32 x 1/2
Left Side Guard
Motor Pump Combo, 1 phz Low
Motor Pump Combo, 1 phz High
Motor Pump Combo, 3 phz Low
Motor Pump Combo, 3 phz High
Coil Only 24 vac.
Control Transformer
Cartridge Valve with Coil
Cartridge Valve Only
Dust Cover
Foot Control
Hand Control
Hose Kit
Junction Box
Motor Contactor
Single Phz. Motor Low Speed
Single Phz. Motor High Speed
Three Phz. Motor Low Speed
Three Phz. Motor High Speed
Pump 0.6 Disp.
Pump 0.73 Disp.
Pump 0.122 Disp.
Pump 0.153 Disp.
Reservoir Breather Cap
Hydraulic Oil Reservoir
ITEM NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
*17
*18
*19
*20
*21
*22
*23
*24
*25
*26
*27
*28
*29
*30
*31
*32
*33
*34
*35
*36
*37
*38
*39
*40
QTY
2
2
6
4
1
12
1
2
1
4
1
2
1
4
4
1
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
PART NO.
GLT-CP-1
GLT-CYL
GLT-HPC
GLT-CP-2
GLT-RSG
GLT-SC
GLT-PLGD
GLT-BLT-1
GLT-TG
GLT-WSR-1
GLT-BKT
GLT-NUT-1
GLT-CB
GLT-TGB
GLT-MS
GLT-LSG
GLT-MPA-1A
GLT-MPA-1B
GLT-MPA-3A
GLT-MPA-3B
GLT-CO
GLT-CT
GLT-CV-CO
GLT-CVO
GLT-PU-DC
GLT-FC
GLT-HC
GLT-HK
GLT-JB
GLT-MC
GLT-MTR-1A
GLT-MTR-1B
GLT-MTR-3A
GLT-MTR-3B
GLT-PMP-0.06
GLT-PMP-0.73
GLT-PMP-0.122
GLT-PMP-0.153
GLT-PU-RBC
GLT-PU-RES
ENGINGEER NO.
2848
04-021-004
45286
10-433-10
04-024-016
32416
GLT-PLGD
27745
04-015-029
33214
04-016-021
37021
04-016-010
01-145-010
24189
04-024-017
GLT-MPA-1A
GLT-MPA-1B
GLT-MPA-3A
GLT-MPA-3B
6316024
01-129-001
SV08-20-S-O-N-24AG
SV08-20-S-O-N
GLT-PU-DC
01-522-012
01-522-015
GLT-HK
AB-664JS
E9.10-24AC
01-135-032
01-135-043
01-135-029
01-135-030
01-143-905
01-143-906
01-143-907
01-143-908
GLT-PU-RBC
GLT-PU-RES
*Not shown in drawing
