Vestil PST series - Manual (Page 12)

12
PARTS IDENTIFICATION - Scissor Table - Model EHLT
ITEM
NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
29
30
PART
NUMBER
a/l
ST-CYLPIN
ST-CYLBRG
ST-CYL
ST-RLR
ST-RLRBRG
ST-TRBRG
a/l
a/l
ST-HP
a/l
ST-SPP
a/l
ST-BRG
ST-CRB
a/l
a/l
ST-TGCNR
a/l
a/l
a/l
ST-TGA
ST-HDW
ST-LS
a/l
ST-TGAE
ST-TGAE
a/l
a/l
DESCRIPTION
Pin, Roller 3/16" dia. x 1-1/8" lg.
Pin, Cylinder Pivot 1-1/8" dia.
Bearing, Sleeve 1-1/8" dia. x 3/4" lg.
Cylinder, Hydraulic 3" dia x 10" stk
Roller, 3-1/4" dia. x 3/4"w
Bearing, Sleeve 1-1/8" dia. x 5/8" lg.
Washer, Thrust Bearing 1-1/8" dia. x .06 thk.
Retainer Snap Ring 1-1/8" dia. External
Washer, Thrust Bearing 1-1/2ID x .06 thk.
Pin, Hinge 1-1/8 dia.
Shim, Machinery Bushing 1-1/8" ID x .06 thk.
Pin, Scissors Pivot 1-1/2" dia.
Bolt, Shoulder 3/8" dia. x 1-1/2" lg.
Bearing, Sleeve 1-1/2" dia x 1-1/2" lg.
Bolt, Cylinder Retainer
Nut, Hex Nylock 1/4-20 unc
Washer, Flat 1/4 nom ID
Toe Guard Support
Screw, Hex HD 1/4-20 unc x 2-1/2" long
Nut, Hex Jam 1/2-13 unc
Screw, #8-32 x 1/2 lg Flat HD Socket Cap
Toe Guard Actuator
Specialty Hardware, Toeguard
Switch, Electrical Limit N.C.
Screw, #4-40 x 1/2 lg. Button Head Sock Cap
Toe Guard End L-Shaped
Toe Guard Side L-Shaped
Shim, Machinery Bushings 1-1/2" dia. x .06 thk
Nut, Hex Nylock 5/16-18 unc
QTY
1
1
6
1
4
4
8
12
4
4
4
2
2
2
1
4
4
4
4
1
2
2
2
2
4
2
2
2
2
ENGINEER
NUMBER
a/l
24-112-02
01-111-002
99-021-901
01-027-001
01-111-001
01-115-001
a/l
01-115-003
01-112-004
a/l
01-112-019
a/l
01-111-003
01-118-001
a/l
a/l
01-015-009
a/l
a/l
a/l
01-015-008
01-145-010
01-022-022
a/l
01-015-912
01-015-912
a/l
a/l
**PLEASE SUPPLY SERIAL NUMBER AT TIME OF ORDER**
