Vanguard TRM-203_403 User Manual
Page 63
REV 1 TRM-203 AND TRM-403 USER’S MANUAL
59
d. The following screen will be displayed:
This warning reminds the operator that the next sequence of test steps will run current
through the test load. Press any key to continue.
e. The following screen will be displayed:
Set the LTC or Voltage Regulator to the lowest position either manually or by pressing
and holding the LTC
[LOWER]
button. Press any key to continue.
f. The following warning screen will be displayed:
Press the
[START]
key to run the test.
g. The following screen will be displayed momentarily:
calibrating
please wait...
DYNAMIC LTC H/X1-H/X0
"START" TO RUN TEST
OR
"STOP" TO ABORT
SET LTC/VREG To
LOWEST TAP POSITION.
PRESS
ANY KEY WHEN READY
***** WARNING! *****
DANGEROUS FLASH-OVER
WILL OCCUR IF CABLES
ARE DISCONNECTED!
********************
