REV 1 TRM-203 AND TRM-403 USER’S MANUAL

k. The following screen will be displayed:

Press the

[START]

key to run the test.

l. The following screen will be displayed momentarily:

After the TRM finishes its internal calibration, the following screen will be displayed:

This is only an informational screen to remind the operator that a test is in progress. The
display duration of this message depends on the size of the winding’s inductance. The
TRM will ramp up the current and then display the following screen:

Press the

[ENTER]

key.

PRESS "ENTER" 00:15

TO START LOGGING...

I = 39.92 AMPS

** XFMR ENERGIZED! **

*XFMR CHARGING*

please wait...

I = 1.01 AMPS

** XFMR ENERGIZED! **

calibrating

please wait...

SPEC TEST H/X1-H/X0

40 amp test

"start" to run test

"stop" to abort
