REV 1 TRM-203 AND TRM-403 USER’S MANUAL
51
3.12 Performing a Special Resistance Test
The Special Resistance Test is used to conduct a resistance test for a pre-defined period ranging
from 1 to 90 minutes. The resistance data is recorded either at 30 second or 60 second
intervals. Use the steps below to perform a Special Resistance Test:
a. Start from the “START-UP” ” menu:
Press the [1] key (RUN TEST).
b. The following screen will be displayed:
Press the
[2]
key (SPECIAL RES TEST).
c. The following screen will be displayed:
Select the phase to test by pressing the corresponding numeric key on the keypad. For
this example, we will be testing phase H/X1-H/X0, so press the
[1] key.
SELECT PHASE:
1.
H/X1-H/X0 (YN PH A)
2. H/X2-H/X0 (YN PH B)
3. H/X3-H/X0 (YN PH C)
4. H/X1-H/X3 (Δ PH A)
5. H/X2-H/X1 (Δ PH B)
6. H/X3-H/X2 (Δ PH C)
1. RESISTANCE TEST
2. SPECIAL RES TEST
3. DYNAMIC LTC TEST
4. DEGAUSS WINDING
1. RUN TEST
2. SETUP
3. USER DIAGNOSTICS
07/31/12
13:12:11
22 °C 72°F
