REV 1 TRM-203 AND TRM-403 USER’S MANUAL
47
After the TRM finishes its internal calibration, the following screen will be displayed:
p. The TRM determines when the resistance reading is stable and displays the resistance
values on the LCD screen as shown below:
Press the [ENTER] key to accept and save the readings for this tap.
q. The following screen will be displayed momentarily:
Once the reading has been saved, the following screen will be displayed:
Set the LTC or Voltage Regulator tap position to the position indicated on the LCD screen
and press the
[START] key.
The TRM will continue the test and display the results as in step n. Repeat steps p
through q for all “Lower” positions and then through all “Raise” positions.
set tap to 2 lower
"START" to CONTINUE
** XFMR ENERGIZED! **
*XFMR CHARGING*
I = 39.91 AMPS
R = 1.491
m Ω
===
>
TEST SAVED!
<
===
** XFMR ENERGIZED! **
TEST IN PROGRESS 7
I = 39.91 AMPS
R = 1.491
m Ω
"ENTER" TO ACCEPT TAP
** XFMR ENERGIZED! **
*XFMR CHARGING*
H/X1-H/X0
please wait...
I = 39.98 AMPS
** XFMR ENERGIZED! **
