ACC/EM3+ PANEL KIT
Installation Instructions
ACC/EM3+ PANEL KIT Installation Instructions TG200202 Issue 1/A 13/4/99
2
Place DIN rail on temporary
support tabs
140 mm
125 mm
45 mm
INSTALLATION
(continued)
Cut holes in panel
6
a
use frame as template
b
cut and drill
Screw frame to panel
7
Clip on bezel
8
plastic cup
frame
tighten
2 screws
panel
9
Clip meter to rail
10
a
b
c
