TREND ACC_STAR3DIN_PANELKIT User Manual
Page 2
ACC/STAR3DIN/PANELKIT
Installation Instructions
ACC/STAR3DIN/PANELKIT Installation Instructions TG200338 Issue 2/B 17/09/07
2
EM-MPO/STAR3DIN
Installation Instructions
TG200770 steps 1 to 7
INSTALLATION
(continued)
Fix Frame to Panel
5
Connect Meter
6
Ensure Meter is switched off
7
Fix Meter to DIN Rail
8
O
I
(a)
Push rods through hole
(b)
Push clamping blocks onto rods
(c)
