— 1 —
Overview
The MOXA EtherDevice™ Switches, EDS-205 series, are entry-level 5-
port Ethernet Switches that provide a cost-effective solution for your
industrial Ethernet connection.
For EDS-205, you could choose either DC power input from 12 to 48 V
or AC power input from 18 to 30V. These products can operation from –
10 to 60
o
C, and the rugged hardware design makes EDS-205 perfect
for ensuring that your Ethernet equipment can meet demanding
industrial applications.
NOTE Throughout this Hardware Installation Guide, we use EDS
as an abbreviation for MOXA EtherDevice Switch:
EDS = MOXA EtherDevice Switch
Package Checklist
MOXA EDS-205 is shipped with the following items. If any of these
items is missing or damaged, please contact your customer service
representative for assistance.
y 1 EDS-205
y Hardware Installation Guide
y MOXA Product Warranty booklet
Features
High Performance Network Switching Technology
y 10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing
y IEEE
802.3/802.3u/802.3x
y Store and Forward switching process type, 1024 address entries
Industrial Design
y Operating temperature ranges from -10 to 60 o
C
y Power inputs DC: 12 to 48 V, AC: 18 to 30 V 47~63 Hz
y IP 30, plastic case
y DIN-Rail mounting ability
