RD-IQ Room Display Installation Instructions TG200492 Issue 1/G 16/01/07 5
Installation Instructions RD-IQ
INSTALLATION (continued)
Engineer Communication 12
S P E N G
1 2 3 4
a
b
c
d ,
ENG + 4
Sensor number Sx
(x = 1 to 9) if Sensor number OK
e
f
g ,
Setpoint Knob number Ka
(a=1 to 9) if Setpoint Knob number OK
h
i
j ,
Occupation Status Knob
number Kb (b=1 to 9) if Occupation Status Knob number OK
k
l
m
,
Fan Speed Knob number
Kc (c=1 to 9)
n
o
p
Data Validation Mode if no changes made
q Normal Mode
if required to change from defaults
Engineer
Communication Mode
RD checks settings valid - may declare errors - see step 15
if Fan Speed Knob number OK
x
a
b
c
default = S9
default = K1
default = K7
default = K6
