SDU-LON Installation Instructions TG200599 Issue 2, 6/10/08 11
Installation Instructions SDU-LON
Set up Parameters 23
Set up the following parameters for IQL using SDU:
Knobs
Switches
Time Zone
Day of week (1 to 14) Period (1 to 3)
Start hours, minutes Stop hours, minutes
Time hrs, minutes, day of month, month, year
daylight saving on, day of month, month
daylight saving off, day of month, month
Calendars Use (next, Free, every)
Start date
Stop date
Special day type for the zone
SDU Data Sheet
TA200559
If required
Note that if a 963 is to centrally control the IQL’s occupation state, then the SDU time zone’s times
should be left nulled at 00:00.
Note that if a 963 is centrally synchronising time, it should do so using a timemaster which will in
turn synchronise the SDU.
3 Installation (continued)
