Set Up Jitter Measurements
1. Touch Analysis → Jitter Kit... on the menu bar,then touch the Measure tab to access the Measure
dialog.
2. Touch the Show Table checkbox to display the Jitter Kit Measurement Table below the grid.
3. Touch the Clear Sweeps Every Acq checkbox to clear data from every sweep (acquisitions).
Note: Touch Clear Sweeps Now to clear data from sweeps (acquisitions). If you touch it during
waveform readout, it cancels the readout.
4. For each parameter touch a number button, then touch the On checkbox to enable the parameter.
5. Touch the parameter button alongside the checkbox. A pop-up menu of parameters categorized by
type appears.
l
Display only icons by touching the icon button at the bottom of the menu.
l
Display the icons in list form, along with an explanation of each parameter, by touching the
list button.
l
Use the Up/Down buttons to scroll through the list of parameters.
Note: Depending on the measurement parameter you select and whether you are using shared or
individual settings, you can define measurement settings in the right hand dialogs that appear to the
right of the main dialog. If you are using shared parameter or gate settings, the measurement
parameter uses those shared settings as defined on the Source Setup and Gate dialogs. If you are
using individual parameter or gate settings, you can define measurement settings in the right hand
dialogs.
