SPECIFICATIONS: PMC2PCI-64
Input Bus: PCI, 32 or 64-bit.
Output Bus: PMC, PCI Mezzanine cards, 32 or 64-bit.
Voltage:
Inputs 5V @ 20 mA, +/- 12V @ 50 mA
Output Ratings +5V, Jumper selectable to 5 Amp or 1 Amp limit.
+3.3V at 2.5 Amp.
+/- 12V at 1 Amp.
Drop Across the Switches 40 millivolts drop for every 1 Amp drawn for +5V, +3.3V and +VIO
30 millivolts drop for every 1 Amp drawn for -12V.
30 millivolts drop for every 100 milliampere drawn for +12V.
Propagation Delay: Less than 500 picoseconds from the system bus to the Mezzanine board.
Controls:
On-Off SPST switch on-board or the external logic input.
Bus Signals Bus signals can be turned on all at once or selectively in groups, via the dip
switch or an external I/O control.
Outputs:
J3 +5V current measurement, each Volt represents 1 Amp.
J4 +12V current measurement, each Volt represents 1 Amp.
J5 +3.3V current measurement, each Volt represents 1 Amp.
JP14 JP14-1 to JP14-32, all pins on the B side, 64-bit extension.
JP13 JP13-1 to JP13-32, all pins on the A side, 64-bit extension.
JP1 JP1-1 to JP1-62, all pins on the B side, 32-bit main bus.
JP2 JP2-1 to JP2-62, all pins on the A side, 32-bit main bus.
NOTE: The signals at JP1, JP2, JP13 and JP14 are active when the extender power is on and tri-
stated when the power is off.
Mechanical Dimensions:
Height 2.2 inches
Length 9.6 inches
