SPECIFICATIONS: PCIX6432-5, PCIX6466-3
Bus: PCIX6432-5; PCI, 32-bit or 64-bit, 5 Volt and Universal, 33 Mhz.
PCIX6466-3; PCI, 32-bit or 64-bit, 3 Volt and Universal, 66 Mhz.
Voltages:
Inputs From PC bus, an external power supply, configurable by jumpers.
Input Requirements 5V @ 20 mA, +/- 12V @ 50 mA
Output Ratings +5V, Jumper selectable to 5 Amp or 1 Amp limit.
+3.3V at 2.5 Amp.
+/- 12V at 1 Amp.
Drop Across the Switches 40 millivolts drop for every 1 Amp drawn for +5V, +3.3V and +VIO.
30 millivolts drop for every 1 Amp drawn for -12V.
30 millivolts drop for every 100 milliampere drawn for +12V.
Propagation Delay: Less than 500 pico-seconds from the PC bus to the UUT.
The switch propagation delay is rated at only 250 pico-seconds.
Controls:
On-Off SPST switch on-board or external logic input
Bus Signals Bus signals can be turned on all at once or selectively in groups, via the dip
switch or an external I/O control.
Outputs:
J3.2 (J3 for Rev C and below) +5V current measurement, each Volt represents 1 Amp.
J3.4 (J4 for Rev C and below) +12V current measurement, each Volt represents 1 Amp.
J3.3 (J5 for Rev C and below) +3.3V current measurement, each Volt represents 1 Amp.
JP1 JP1-1 to JP1-32, all pins on the B side, 64-bit extension, 100 mil centers.
JP2 JP2-1 to JP2-32, all pins on the A side, 64-bit extension, 100 mil centers.
JP13 JP13-1 to JP13-62, all pins on the B side, 32-bit main bus, 100 mil centers.
JP14 JP14-1 to JP14-62, all pins on the A side, 32-bit main bus, 100 mil centers.
NOTE: The signals at JP1, JP2, JP3 and JP4 are active when the extender power is on, and
tri-stated when the power is off.
Mechanical Dimensions:
Height 1.6 inches
Length 9.6 inches
