26
5.2.9 SATA/STP Frame Members
Note: All members return the content of the matching field name ("in.xyz" returns the value of
field "xyz") based on the SATA specification.
5.2.9.1 Common SATA/STP Frame Members
in.Trp_STPFrameType
in.Trp_PMPort
5.2.9.2 Register Host To Device Frame Members
in.Trp_C
in.Trp_Command
in.Trp_Features
in.Trp_SectorNumber
in.Trp_CylLow
in.Trp_CylHigh
in.Trp_DevHead
in.Trp_SectorNumExp
in.Trp_CylLowExp
in.Trp_CylHighExp
in.Trp_FeaturesExp
in.Trp_SectorCount
in.Trp_SectorCountExp
in.Trp_Control
5.2.9.3 DMA Setup Frame Members
in.Trp_D
in.Trp_I
in.Trp_A
in.Trp_DMABufferidLow
in.Trp_DMABufferidHi
in.Trp_DMABufferOffset
in.Trp_DMABufferTransferCount
Note: Follow the same procedure explained in
Section 5.2.4 for the remaining
Command/Function/OpCode specific frame members:
5.2.9.4 Register Device To Host Frame Members
5.2.9.5 Set Device Bits Frame Members
5.2.9.6 DMA Activate Frame Members
5.2.9.7 Bist Activate Frame Members
5.2.9.8 PIO Setup Frame Members
5.2.9.9 DATA Frame Members
