5.2.8.3

SMP Response Frames members

in.Trp_FuncResult
in.Trp_RespLength

5.2.8.3.1 Report General Frame members

in.Trp_ExpanderChgCount

in.Trp_ExpanderRouteIdx

in.Trp_LongResponse
in.Trp_NumofPhys
in.Trp_Externallyconfigurableroutetable
in.Trp_Config
in.Trp_Configuresothers
in.Trp_OpenRejectRetrySupported
in.Trp_ContinueAWT
in.Trp_SelfConfiguring
in.Trp_ZoneConfiguring
in.Trp_Tabletotablesupported
in.Trp_EnclosureLogicalIdentifier
in.Trp_businactivitytimelimit
in.Trp_maximumconnecttimelimit
in.Trp_SMPI_Tnexuslosstime
in.Trp_Zoningenabled
in.Trp_Zoningsupported
in.Trp_Physicalpresenceasserted
in.Trp_Physicalpresencesupported
in.Trp_ZoneLocked
in.Trp_Numberofzonegroups
in.Trp_Savingzoningenabledsupported
in.Trp_Savingzonepermissiontablesupported
in.Trp_Savingzonephyinformationsupported
.
.
.
And so on

Note: Follow the same procedure explained in

Section 5.2.4

for the remaining

Command/Function/OpCode specific frame members:

5.2.8.3.1.1.1.1 Report Manufacturer Info Frame members

5.2.8.3.1.1.1.2 Discover Frame members

5.2.8.3.1.1.1.3 Read GPIO register

5.2.8.3.1.1.1.4 Report self-configuration status

5.2.8.3.1.1.1.5 Report zone permission table members

5.2.8.3.1.1.1.6 Report zone manager password members

5.2.8.3.1.1.1.7 Report broadcast members

5.2.8.3.1.1.1.8 Report phy error log members
