D500-46-00

I56-2174-004

System Sensor warrants its enclosed product to be free from defects in

materials and workmanship under normal use and service for a period

of three years from date of manufacture. System Sensor makes no other

express warranty for the enclosed product. No agent, representative,

dealer, or employee of the Company has the authority to increase or alter

the obligations or limitations of this Warranty. The Company’s obliga-

tion of this Warranty shall be limited to the replacement of any part of

the product which is found to be defective in materials or workman-

ship under normal use and service during the three year period com-

mencing with the date of manufacture. After phoning System Sensor’s

toll free number 800-SENSOR2 (736-7672) for a Return Authorization

number, send defective units postage prepaid to: System Sensor, Returns

Specifications:
Electrical

Mechanical

Supply Voltage -

Min.

8.5 Volts (Power limited)

Height:

4.5 inches

Max.

30 Volts (Power limited)

Width:

4.0 inches

Max.Ripple Voltage:

30% of applied voltage

Depth:

1.25 inches

Max. Standby Current:

30mA (12 detectors on loop)

Weight:

0.5 pound

Max. Alarm Current:

90mA

(Includes packaging

Alarm Contact Ratings:

0.5 Amp @ 36 V DC, Resistive

materials)

Maintenance Contact Ratings: 2 Amp @ 30 V DC, Resistive

Min. Reset Voltage:

6 Volts

Min. Reset Time:

0.3 sec.

Operating Temperature Range: 14°F to 122°F (-10°C to 50 °C)

Operating Humidity Range:

0 to 95% RH non-condensing

Storage Temperature Range:

–4°F to 158°F (–20°C to 70 °C)

Initial Communication Cycle:

2-6 minutes after power-up or panel reset

EZ Walk Test Available:

6 minutes after power-up or panel reset

2-wire compatibility

Min. loop voltage:

10 Volts

Max. loop voltage:

11.5 Volts

Max. loop resistance:

50 ohm

Max. loop ripple:

1 Vpp

Max. Loading Capacitance:

0.01 mF

Max. Alarm current:

40 mA

Max. Reset Voltage:

0.3 V

Alarm Delay:

Min. Alarm reset time:

0.3 sec.

Max. normal load current:

1.25 mA

Zone Type:

Standard

EOL Device:

3.9 KΩ (0.25W, 5%)

Loop style:

B, D

Compatibility/Zone identifier: A

Max. detectors per zone:

Models 2W–B and 2WT–B:

Model 2WTR–B:

Model 2WTA–B:

NOTE: When used with the RRS–MOD reversal relay/synchroniza-

tion module and the 2W–MOD2, a maximum of 12 2WTA–B detec-

tors are allowed per zone.

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

Three-Year Limited Warranty

Department, RA #__________, 3825 Ohio Avenue, St. Charles, IL 60174.

Please include a note describing the malfunction and suspected cause

of failure. The Company shall not be obligated to replace units which

are found to be defective because of damage, unreasonable use, modi-

fications, or alterations occurring after the date of manufacture. In no

case shall the Company be liable for any consequential or incidental

damages for breach of this or any other Warranty, expressed or implied

whatsoever, even if the loss or damage is caused by the Company’s

negligence or fault. Some states do not allow the exclusion or limita-

tion of incidental or consequential damages, so the above limitation or

exclusion may not apply to you. This Warranty gives you specific legal

rights, and you may also have other rights which vary from state to state.
