Steelcraft Automotive 81330 REAR BUMPER GUARD User Manual
Installation instructions
Page 1 of 2
8/22/07 (AM)
PARTS LIST:
1 Rear Bumper Guard
4 12-1.75mm x 30mm Hex Head Bolts
2 Mounting Brackets
4 12mm Nylock Nuts
2 10mm Double Bolt Plates
8 12mm ID x 37mm OD x 3mm Flat Washers
4 10mm Nylock Nuts
4 10mm ID x 30m ID x 2.5mm Flat Washers
INSTALLATION INSTRUCTIONS
REAR BUMPER GUARD
08-10 FORD ESCAPE / 08-10 MAZDA TRIBUTE
PART NUMBER
Driver Side
Mounting Brackets
Passenger Side
Mounting Brackets
Bolt Plates(the picture
for reference )
Installation
Complete
