Steelcraft Automotive 34120 TAILLIGHT GUARD User Manual
Page 2
TAILLIGHT GUARD
05-11 NISSAN XTERRA
Page 2 of 2
7/7/11 Rev1 (DP)
Driver Side Installation Shown
Mark the spot then drill 1/16"
pilot hole for the Support Bracket
4mm x 15mm
Phillips Screw
IMPORTANT: Any cutting or drilling tool may break or
shatter. Government regulations require safety glasses
& equipment at all times when cutting or drilling.
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Complete
Installation
(2) ST6.3mm x 25mm
Philips Screws
(2) 8mm Flat Washers
(1) ST3.5mm x 12mm
Phillips Screw
(1) 4mm Flat Washer
Remove (2)
factory screws
