Steelcraft Automotive 422509p 5 PREMIUM OVAL SIDE BAR - Manual (Page 2)

5" OVAL BENT END SIDEBARS
09-12 DODGE RAM 1500 CREW CAB
10-12 DODGE RAM 25-3500 CREW CAB
EXCLUDES VEHICLES EQUIPPED WITH DIESEL EXHAUST FLUID SYSTEMS
Page 2 of 3 12/16/11 (DP)
Washers, (Figure 4). Do not tighten hardware at this time. IMPORTANT: If you are having any
difficulty with installation, check Mounting Bracket location first. Use the illustration on Page 1
to identify the Mounting Brackets.
6. Properly level and adjust the Sidebar and tighten all hardware at this time.
7. Repeat Steps 2 - 6 for passenger Sidebar installation.
8. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to add a protective layer
over the finish. Do not use any type of polish or wax that may contain abrasives that could damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild soap may be
used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
Driver Side Installation Pictured
12mm x 40mm Bolt x 10mm Nut
Plate w/ 12mm Plastic Retainer
(Fig 1A) Driver/Left front mounting location
Fig 2B
(Fig 1B) Driver/Left center mounting location
(Fig 1C) Driver/Left rear mounting location
Front
Front
Rear
Fig 2A
