Steelcraft Automotive 412420 4 OVAL SIDE BAR User Manual
Page 3
4
” OVAL STRAIGHT SIDEBARS
99-03, 04 HERITAGE FORD SUPER CAB F-150, F-250 LIGHT DUTY 4-DOOR
Page 3 of 3 7/16/12 Rev1(DP)
Front
Front
Front
Front
10mm Lock Washers
10mm Flat Washers
10mm Hex Nuts
Remove large oval
rubber plugs
Narrow Double Bolt
Plate (use for driver side
rear 3-door 97-98 only)
Double Bolt Plate
(Fig 7) Driver/Left Side Installation Illustrated
(Fig 5) Driver side front (angled) Bracket
(Fig 6) Driver side rear (straight) Bracket
Sidebar to Bracket
8mm Lock Washers
8mm Flat Washers
8mm Hex Bolts
