Steelcraft Automotive 440900 4 OVAL SIDE BAR - Manual

PARTS LIST:
1 Passenger/Right Side Bar 8 8-1.25mm x 30mm Hex Head Bolts
1 Driver/Left Side Bar 16 8X22mm O.D.X1.5mm Flat Washers
1 Front Passenger/Right Side Mounting Bracket 16 8mm Lock Washers
1 Rear Passenger/Right Side Mounting Bracket 8 8-1.25mm Nuts
1 Front Driver/Left Side Mounting Bracket
1 Rear Driver/Left Side Mounting Bracket
PROCEDURE:
1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS
CAREFULLY.
2. On the passenger/right side, if equipped, remove the existing running board by removing the four nuts
holding mount to inside of body. Install the two passenger/right side mounting brackets with the removed
stock nuts, leave nuts loose for now. NOTE: Holes in brackets are off set, install with holes towards front of
truck, passenger/right side shown. See Fig. #1
3. If not equipped with factory running boards – then use the four supplied 8mm nuts, washers & lock
washers to install mounting brackets to truck.
4. Repeat procedures 2 & 3 for driver/left side.
5. Install side bar onto mounting brackets using four 8X25mm hex head bolts, four 8mm lock washers & four
8mm flat washers. Leave bolts loose – short end whole pattern installs towards the front of truck,
passenger/right side shown.
6. Repeat procedure #5 on driver/left side.
7. Level and adjust side bars as desired and tighten.
8. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
FIG. #1PASSENGER SIDE SHOWN FIG. #2 PASSENGER SIDE SHOWN
Page 1 of 1 3/08/07 (DL)
OFF CENTER HOLES EXISTING NUTS
NOTE: If vehicle is not equipped with
factory Sidebars use the included
8mm Hex Nuts
8mm Lock Washers
8mm Flat Washers
SHORT END HOLE
PATTERN
INSTALLATION INSTRUCTIONS
SIDE BAR
05-07 NISSAN FRONTIER
PART NUMBER 440907
