Steelcraft Automotive 223200 3 ROUND SIDE BAR User Manual
Page 2
3" SIDEBARS
2011-14 JEEP GRAND CHEROKEE
Page 2 of 3 10/1/12 (DP)
(Fig 1) Driver side front pictured
Fig 3
(Fig 2) Driver side rear pictured
Remove rubber plug
Front
To determine the correct mounting
location, locate the three pairs of (2)
factory holes in the pinch weld
Fig 4B
Front
(Fig 4A) 12mm x 40mm
Bolt Plate
Insert Bolt Plates then
rotate clockwise until it
stops for proper
installation
Rear
Front
