Steelcraft Automotive 290600 3 ROUND SIDE BAR User Manual
Page 3
SIDEBAR
2012-13 MERCEDES BENZ ML CLASS
Page 3 of 3
(DP)
9/27/2013
(Fig 10)
Driver Side Installation Pictured
(Fig 7) Driver side front Mounting Bracket pictured
(Fig 8) Driver side rear Bolt Plate
and Plastic Retainer installed
(Fig 9) Driver side rear Mounting
Bracket installation pictured
Complete Installation
12mm Flat Washer
12mm Lock Washer
12mm Tall Coupling Nut
Front
Rear
Rear
12mm Flat Washer
12mm Lock Washer
12mm Tall Coupling Nut
(2) 10mm x 30mm Hex Bolts
(4) 10mm Flat Washers
(2) 10mm Nylon Lock Nuts
Rear
