Steelcraft Automotive 211400 3 ROUND SIDE BAR User Manual
Page 3
Page 3 of 4
7/6/07 (AM)
Passenger Side Mounting Brackets Shown
Front of Vehicle
“A” Bracket
“B” Bracket
10mm Clip Nut
Rear Mounting Bracket shown
- 10mm x 120mm Hex Bolt
- 10mm Lock Washer
- 10mm Flat Washer
(To pinch weld)
- 10mm x 30mm Hex Bolt
- 10mm Lock Washer
- 10mm Hex Nut
- 10mm Flat Washer
85mm Tube
Spacer
Installation Complete
Figure 3
Figure 4
Figure 5
