Steelcraft Automotive 170700 RUNNING BOARD User Manual
Page 8
ALUMINUM VIEWPOINT RUNNING BOARDS
2013 HYUNDAI SANTA FE
Page 8 of 8
4/15/13(DP)
(Fig 14) Passenger side rear
Bracket installation pictured
Complete Installation
Insert (3) T-Bolts into each
channel and slide into position
Front
(2) 6mm T-Bolts
(2) 6mm Flat Washers
(2) 6mm Lock Washers
(2) 6mm Hex Nuts
Fig 15
Fig 16
10mm Flat Washer
10mm Lock Washer
10mm Hex Nut
6mm x 25mm Hex Bolt
6mm Lock Washer
6mm x 22mm Large
Flat Washer
Rear
