Steelcraft
Installation Instructions
Sport Bar #79030S
Part List
1
Sport Bar
1 Lower bracket (driver)
1 Lower bracket (passenger)
1 T Bracket (Driver)
1 T Bracket (Passenger)
2 ½ x 2 Bolt Plate
2 ½ Flat Washer
2 ½ Nylon Nut
4 7/16 x 1 ¼ Hex Bolt
6 7/16 Hex Nut
12 7/16 Flat Washer
2 7/16 x 1½ Hex Bolt
2 ¼ x 1 Hex Bolt
2 ¼ Nylon Nut
2 ¼ Flat Washer
Procedure:
1. Remove content from box and check for damage, verify all parts are present, read
instructions carefully.
2. detach lower liner located in front of vehicle and set aside ( temporarily)
3. Detach rubber hose from retainer clip located on driver side see fig 1.
4. Remove oval rubber plug located behind body mount bushing and insert ½ x 2bolt
plate (see Fig 2.)
5. Determine driver and passenger lower bracket and install using (1) ½ flat washer,
(1) ½ Nylon nut, Leave loose (passenger side shown) see Fig 2.
6. Remove existing bolt (temporarily) on located on radiator support and install T
bracket using existing bolt. (1) ¼ x1 hex bolt (1) ¼ flat washer (1) ¼ Nylon Nut
leave loose ( passenger side shown)
7. Repeat procedure 4, 5, 6 on opposite side.
