Steelcraft Automotive 70360 BULL BAR User Manual

Installation instructions

background image

Page 1 of 3

12/06/07 (AM)

PARTS LIST:

1 Bull Bar

2 12-1.75mm x 140mm Hex Head Bolts

1 Driver/Left Mounting Bracket

3 12mm Lock Washers

1 Passenger/Right Mounting Bracket

5 12m ID x 29mm OD x 3mm Flat Washers

1 12-1.75mm x 35mm Bolt Plate

3 12mm Hex Nuts

4 8-1.25mm x 30mm Hex Head Bolts

4 8mm Lock Washers

4 8mm ID x 17mm OD x 1.5mm Flat Washers

2 Tube Spacers

– 83mm

INSTALLATION INSTRUCTIONS

3” BULL BAR

07- 08 GMC SIERRA 1500 / CHEVY SILVERADO 1500

PART #

Driver Side

Mounting Bracket

(1 pc)

Passenger Side

Mounting Bracket

(1 pc)

12-1.75mm x 35mm

Bolt Plate

(1 pc)

Tube Spacers

(2 pcs)
