Installation instructions

background image

Page 1 of 3

12/06/07 (AM)

PARTS LIST:

1 Bull Bar

4 10-1.50mm x 30mm Hex Head Bolts

1 Driver/Left Frame Bracket

4 10mm Lock Washers

1 Passenger/Right Frame Bracket

4 10mm Hex Nuts

1 Driver/Left Bull Bar Bracket

8 10mm ID x 26mm OD x 3mm Flat Washers

1 Passenger/Right Bull Bar Bracket

4 12-1.75mm x 35mm Hex Head Bolts

4 8-1.25mm x 25mm Hex Head Bolts

4 12mm Lock Washers

4 8mm Lock Washers

4 12mm Hex Nuts

4 8mm ID x 22mm OD x 3mm Flat Washers

8 12mm ID x 29mm OD x 3mm Flat Washers

INSTALLATION INSTRUCTIONS

3” BULL BAR

07-08 GMC SIERRA 2500 / CHEVY SILVERADO 2500

PART NUMBER

Passenger Side Frame Bracket

Driver Side Frame Bracket

Passenger Side
Bull Bar Bracket

Driver Side

Bull Bar Bracket
