Steelcraft Automotive 71320 BULL BAR User Manual
Installation instructions

PARTS LIST:
1 Bull Bar
1 Driver/Left side Mounting Bracket
1 Passenger/Right Mounting Bracket
4 3/8” x 1 ¼” Hex Head Bolts
4 3/8” Nylock Nuts
8 3/8” Flat Washers
PROCEDURE:
1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ
INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
2. NOTE: It may be necessary to remove/relocate front license plate and license plate
bracket. It is not required, but strongly recommended. If local/state law requires a license
plate, license plate relocation kit is available.
3. From front of vehicle remove the driver side bumper mount bolts (Figure 2).
WARNING! Do not remove passenger and driver bumper mount bolts at the same time.
Remove one side at a time.
4. Place Mounting Bracket onto vehicle and line it up against the outer gusset bend on the
frame. Leave about 1/8” clearance between bottom of Mounting Bracket and bumper.
Secure Mounting Bracket to vehicle using the factory bolts (Figure 3). Fully tighten these
bolts at this time.
5. Once the driver side Mounting Bracket is fully tightened, repeat steps 2 - 4 for passenger
side Mounting Bracket.
6. With help position Bull Bar on the outer side of Mounting Brackets. Attach Bull Bar to
Mounting Brackets using the included (4) 3/8” x 1 ¼” Hex Head Bolts, (4) 3/8” Nylock
Nuts, and (8) 3/8” Flat Washers (Figure 4). Do not tighten at this time.
7. Level and adjust Bull Bar as desired, then tighten all hardware at this time.
8. Do periodic inspections to the installation to make sure that all hardware is secure and
tight..
Page 1 of 3
3/16/07
(AM)
INSTALLATION INSTRUCTIONS
BULL BAR
08 FORD SUPER DUTY F250/F350
PART NUMBER
Driver Side
Mounting Bracket
Passenger Side
Mounting Bracket
